7 inch Android Panel PC with Caseless Module

Products Details

Product model WAR-070C-IN10
 Basic parameters CPU: Quad-core Cortex-A7 architecture ;  Frequency 1.2GHzMemory:1GB DDR3Flash:8GB Nandflash
 Display screen  Size: 7 inchResolution:1024×600Wide-temperature type,16000k colors or 24 true colorsLED backlight:lifetime > 25000 hours
Touch screen Capacitance touch screen
     Hardware interface 4 channel RS-232 serial port(COM1,COM2,COM3,COM4) ( TTL as option ) .2 channel RS-485(COM5,COM6)1 channel 1000M Ethernet interface.1 channel USB device interface, support ADB connect to PC to exchange data and debug application.3 channel USB Host interface,support usual USB device such as mouse, keyboard, U disk ,etc.1 channel HDMI interface.1 channel 3.5mm Audio interface.1 channel PH 2.0-4 Power Amplifier interface  (8 Ω 2W) ( Optional )1 channel 2EDG3.5 Power Input interface ( DC12V~24V  )1 channel SD/MMC slot, support mini SD / MMC card .WIFI、4G , GPS  ( optional )
Attention When the serial port is connected, The GND wire of the two devices must be connected to avoid burning the serial chip and affecting communication.
OS Android 7.1.1
Defend degree /
Working environment power:DC 12V-24V (24V as recommendation)working Temperature:-10~50℃    storage temperature:-20~70℃working humidity:10~90%RH
Size No shellsize:188×117×41 (mm)
 Application area industrial control,detection device,instruments and meters,security monitoring,medical apparatus and instruments, intelligent terminals embedded high-end application.
 Software support Support Eclipse、Android Studio、QT Creator、Visual Studio 2015/2017 development,support JAVA/C/C++/C# ,etc .Easy change the user-defined splash screen.

2.1  RS-232 interface

4 channelssupport the highest-level baudrate 115200bps. The corresponding interface in Android system is COM1 ~ COM4 . Interface is PH2.54-4P horizontal connector, TTL is optional .

2.2  RS-485 interface

2 channels, The corresponding port in Android system is COM5COM6.          Interface is PH2.54-3P horizontal connector .Exterior size :188x117x41(mm)
